Description:
Item Name: Electronic Speed Controller
Model: Brushed
Current: 3.3V-6V, long-distance running 2.7A, peak 10A
Size: 20x9mm
Weight: 2g
Usage: suitable for modeling Car, changing toys, intelligent building blocks, etc.
Features:
-Start with the neutral point (when the power is on, you will hear the motor "beep" prompt, throttle channel 1500 (+/-50), you will hear the motor "beep" down, the ESC starts, the motor prompts the ESC to the motor small current And issued, for a motor that is too easy to turn, the motor will turn twice, no surprise.)
-Oil range PWM 700-2300us wide range adaptation
-With out of control protection Loss signal (in the accident, the signal line is broken) The motor stops. (If you connect the signal line with power, please return to the midpoint to restart)
-The ESC has overheat protection. If the ESC temperature exceeds 150 degrees, the motor output stops, the temperature drops to 130 degrees, and the output is re-output.
-(There is optimization of the hollow cup, the initial duty cycle can be adjusted small)
-The original receiver takes power: you can change the battery cable.
Receiver power requirements:
-Use the other 2/3S ESC to power the receiver. When plugging the receiver into the receiver, the load should not exceed the received power supply capacity (bec is usually 1A, except for the receiver, etc., only hundreds of milliamps are available)
-Of course, in the case of 1S, you can reverse the process, add a battery cable to the ESC, and then use the ESC 3P to receive the power supply (1S lithium battery is available for the receiver)
Package Included:
1 x ESC
