20x20mm AuroraRC SupraF7BT F7 Bluetooth Flight Controller w/ 5V 9V BEC & 40A BL_32 3-6S 4 In1 Brushless ESC Stack Support DJI Air Unit for RC Drone FPV Racing - 78.00 €

Specification:

Brand Name: AuroraRC
Item Name: F7 Bluetooth Flight Controller & 40A BL_32 4in1 ESC Stack

Mounting Hole for Stack: 20x20mm

Stack Height: 14mm

F7 Bluetooth Flight Controller

Model: SupraF7BT

Item Name: F7 Buletooth Flight Controller w/ 5V 9V BEC

 Input Voltage: 3-6S Lipo (11.1-26V)

MCU: STM32F722RET6 216MHz

Gyroscope: MPU6000

Firmware:  Betaflight JHEF7DUAL

BEC Output: 5V/2A & 9V/3A

Serial Control Port: 6 Channels

Bluetooth: Support Bluetooth (UART4, baud rate 115200, named SUPRAF7BT)

Size: 26.5x30mm

Mounting Hole: 20x20mm, M2

Weight: 8g

40A BLheli_32 4In1 ESC
Con. Current: 40A
Burst Currernt: 60A
Input Voltage: 3-6S Lipo
BEC Output: NO
ESC Programming: BLHeliSuite32
Input Wires: Red 14AWG 100mm ; Black 14AWG 100mm
Output Wires: NO Wires but solder tabs
Input Connectors: XT60 Plug enclosed with package
Size: 40x33x5mm
Mounting Hole: 20x20mm M2 and M3
Weight: 18g
Application: for 100-300mm FPVs
-Support Oneshot42, Oneshot125, DShot150/300/600/1200

Click here to buy separate replace 40A ESC.

Clickhere to buy separate replace F7 Flight Controller.

Package Included:

1x F7 Flight Controller Board

1x 40A 4in1 ESC

8x Anti-vibration Ball

1x Cable

1x Connector

1x bag of Screws
