25.5x25.5mm SPCMaker Whoop F411 F4 OSD Flight Controller Built-in Current Sensor Integrated with 20A BLheli_S 2-4S 4in1 Brushless ESC for Toothpick RC Drone FPV Racing - 55.00 €

Specification:

Brand Name: SPCMaker

Item Name: F4 OSD Flight Controller Built-in 25A 4in1 ESC
Size: 31.4x31.4mm
Mounting Hole: 25.5x25.5mm
Weight: 7g
CPU: STM32F411CEU6 (100MHZ)
MPU: MPU6000 ( SPI)
Firmware: Betaflight SPCMAKERF411(SPCM)

Built-in Betaflight OSD ( AT7456E)
Built-in Current Sensor (Current Coefficient Amp Meter Scale: 300)
- Support WS2812 LED

- Support DSMX/DSM2; TBS Crossfire, IBUS, SBUS Receiver

Input Voltage: 2-4S Lipo
Con. Current: 25A

Burst Current: 40A
Firmware Support: BLHELI_S/JESC

Firmware Version: BLHELI_S (G_H_30)

Motor Connector: 1.25mm 3P spacing Straight Pin Holder

- Support PWM, Oneshot42, Oneshot125, Multishot, Dshot150 and Dshot300, Dshot600

Package Included:

1x SPCMaker F4 Flight Controller Built-in 25A ESC Board
