Summary:
Glad to introduce a new member of GEPRC FC AIO,GEP-F722-45A AIO,it is released now.
GEP-F722-45A AIO adopts MCU STM32F722,which has powerful performance and higher computing speed.It has 5 full UART ports and can connect more external devices.
We designed a 6-pin connector for DJI AIR UNIT MODULE,plug and play.
The BLheili_S 45A ESC can handle 45A continuous current(55A burst), totally supports the 2-6S lipo battery, brings the drone a stronger flight performance.It can support OSD parameter adjustment, buzzer, led and other functions. It is 8.8g ultra light weight, and 26.5mm * 26.5mm mounting hole, suitable for most of the frames on the market.
We pursue lighter weight, smaller volume, more functions and better performance Flight controller.
Specification: ( Manual)
Brand: Geprc
Model: F722-45A AIO
Model Name: F7 Flight Controller AIO 45A ESC
MCU: STM32F722
IMU: MPU6000 gyro/accelerometer(SPI)
Firmware target: GEPRC_F722_AIO
OSD: Betaflight OSD w/ AT7456Ev
UART Ports: R1 T1 / R2 T2 / R3 T3 / R4 T4 / R5 T5
Beeper:YES
LED:YES
USB:Micro USB
BEC output:5V@1A
Intergrated LC Filter
ESC MCU:8BB21F16G
Continuous current:45A
Max. Current:55A (10s)
Input Voltage: 2~6S
Supports: Dshot600,Oneshot,Multishot
BlackBox: 16Mb
Traget: G_H_30
Size: 32x32mm Board
Installing Hole: 26.5Ã26.5mm,M2
Weight: 8.8g
Features:
MCU:STM32F722,with strong performance and higher computing speed.
It has 5 full UART ports, which can connect more external devices
Design 6p connector for DJI AIR UNIT MODULE, and just plug and play .
The BLheili_S 45A ESC can handle 45A continuous current(55A burst), totally support the 2-6S lipo battery, which can bring the drone a stronger flight performance.
Support OSD parameter adjustment, buzzer, led and other functions.
8g ultra light weight
5mm * 26.5mm mounting hole, suitable for most frames
Package Included:
1 x GEP-F722-45A AIO
1 x XT30-7CM-18AWG Power cables
1 x 35V220UF capacitor
1 x SH1.0-6Pin to GH1.25-8Pin cables
8 x M2*6.5mm Damping rings
