OMNIBUS F3 AIO V1.1 Flight Controller with Integrated OSD Barometer Support SD card
Description: User Manual
Item: F3 FC
LiPo Input: 2-4S
Support SD card
Size: 36x36mm
Mount Holes: 30.5x30.5mm
Specification:
STM32 F303 MCU, Runs Betaflight 3.0 firmware
SBUS/PPM input (Pin headers)
8PWM output (1-4Pinheaders and Sh1.0 Plug, 5-6 as Pin headers)
128Mb Flash(16M Byte)
optional Barometer BMP280, you can close it by software.
SPI Sensor MPU6000
Features:
A new generation AIO Flight control for FPV
Based on F303 MCU, using F3 MCU controls OSD over SPI bus in DMA mode
OSD Configuration has been incl. in Betaflight GUI.
Supports SD Card and LIPO direct input (2-4S)
MPU6000 at SPI bus.
4 in 1 Integraded ESC ports
Package included:
1 x FC
