BETAFPV x Insta360 SMO 4K Ultralight 4K Wide Angle & Flow State Stabilization Action Camera for Micro Cinewhoop Beta95X V3 FPV RC Racing Drone
An Action Camera Born for FPV Drones
Meet the SMO 4K Camera - A high-degree ultralight action camera designed for your FPV Drones! Developed by BETAFPV and Insta360, SMO 4K camera only weighs 30g and perfectly fit for FPV drones. It allows pilots to fly faster, longer and do more maneuvers, bringing pilots an extraordinary flying experience and a strong visual impact. Meanwhile, with 4K ultra-wide-angle shots and FlowState stabilization function, pilots can shoot 4K wide-angle video with greater details, and get an ultra-smooth and stable video, which makes SMO 4K camera be the best choice for pilots in search of high-quality video with FPV drones!
To better enjoy the SMO 4K camera, we highly recommend using it on the new pusher whoop drone - Beta95XâV3 Whoop Quadcopter and Beta95X V3 HD Digital VTX.
Description:
Brand: BETAFPV x Insta360
Model: SMO 4K
Weight: 30g
Size: 61.5mmÃ39.4mmÃ29.2mm
Power supply range: 6V-27V (2S-6S Li-Po battery)
Lens aperture: F2.8
35mm equivalent focal length: 16.4mm
Video resolution: 4000x3000@24/25/30fps, 3840x2160@24/25/30/60fps, 2720x1530@24/25/30/60/100fps, 1920x1080@24/25/30/60/120/200fps
Video format: Insv (export through APP or Studio)/ Mp4
Video code: H.264 / H.265
Video mode: Normal video, HDR video, Time-lapse photography, TimeShift mobile time-delay video; Pro stabilization mode (Use Insta360 App/Studio or supported plug-in export to implement FlowStateStabilization)
Video maximum bit rate: 100Mbps
Bluetooth: BLE4.0
Wi-Fi: 5G (standard range approx. 2m)
Micro SD card: UHS-I V30 speed level and above recommended, exFAT (FAT64) format (maximum storage capacity is 1T)
Operating environment: -20°C ~ 40°C
Designed For All Drones
SMO 4K is an ultralight action camera that is designed for mounting on an FPV. Weighing at just 30 grams, and it can be easily mounted and carried on a variety of FPV drones including cinewhoops like Beta95X V3, 3-4'' ducted quads, 4-5'' long-range FPVs and fixed-wing FPVs. Highly recommend the new Beta95XâV3 Whoop Quadcopter, it has a built-in mount for the SMO 4K camera for easy out-of-the-box installation. Meanwhile, its "pusher-style" inverted frame maintains a low center of gravity and makes the drone easier to maneuver.
FPV Stabilization
SMO 4K is backed up with Insta360's proprietary FlowState stabilization algorithm, and it will keep your shots so smooth. What's more, we have added an FPV augmenting model for processing SMO 4K aerial video. Thanks to a new algorithm, the flight footage can stay more clear and steady.
4K Wide Angle
With the SMO 4K action camera, pilots can shoot 4K wide-angle video with greater detail, smoother stabilization and better dynamic range. SMO 4K also can shoot 4K footage with a new ultra-wide FOV option in Insta360 Studio that removes distortion from your shots. In addition, a 100mbps bitrate and H.265 encoding deliver crisp details.
FlowState Stabilization
With 4K wide angle and FlowState stabilization, we specially added an FPV augmenting model on Insta360 Studio for processing SMO 4K aerial video. Thanks to a new algorithm, our flight footage stays clear and steady.
No More Jello Effect
By using the ND16 filter, it can prevent the issue of jello generated in the insane flight. An ND16 filter also acts as a lens protector which can protect your lens while your drone meets a serious crash. In addition, when you fly indoors or at dusk, you can use the UV filter to protect your lens. ND16 filter and UV filter are both provided in the package.
Plug-in and Control
The camera comes with a 6V to 27V power connector that supports 2S to 6S LiPo FPV batteries. Just plug in and go. Pilots can easily connect the SMO 4K with your flight controller for power supply and recording. You can also connect the camera to your flight controller to start and stop recording remotely without having to stop flying.
Ultralight & Easy to Carry on
Adhering to the concept of naked camera, we developed a high-degree lightweight action camera - SMO 4K. With this new camera, you will find it is 30g only which is compatible for all kinds of FPV drones like micro cinewhoop Beta95X V3, 3-4in ducted quad, 4-5in long-range FPV drone and FPV fixed wing.
Multi Camera Mount Holder, Multi Choices of Possibility
We provide three STL files of SMO 4K camera mount holders for different genres of FPV drones, so you can choose any one for your micro whoop, 3-5in drone or FPV fixed wing. It is worth mentioning that the camera mount holder for 3-5in drone is the general mount holder for all action cameras like GoPro. Click it here to reach more.
ND Filter & Lens Protector
UV filter and ND16 filter are both provided. An ND filter also acts as a lens protector. It can equally (or neutrally) reduce the amount of light across the entire spectrum entering your camera sensor without changing the image color. In a nutshell, it's a pair of sunglasses for your camera! But if you fly indoors or at dusk, you can use the UV filter to protect your lens.
Global Availability
SMO 4K is on sale internationally starting today on betafpv.com and at select retailers around the world.
LED Status
Please notice that the SMO 4K indicator light has some differences from the user manual. The specific LED status is as follows.
* When SMO 4K mistakenly detected that it is not charged with a battery, the LED status is blue;
* When SMO 4K mistakenly detected that it is charged with a battery, the LED status is red.
* Both conditions will not affect the performance of SMO 4K. Please refer to the table below for the correct camera LED status.
| LED | Status | Description |
| Blue Light | Flashing | SD card error |
| Blue Light | Solid | Power on & SD card is; Battery signal detected |
| Red Light | Flashing | Recording |
| Red Light | Solid | Battery signal detected |
More accessories for your better installation are SH1.0 4pin cable and UV/ND16 filter.
User Guide
https://docs.google.com/document/d/1-JvDiKzuVnCFE4NH_NrILZ6KxxdMGdBoUiEkMPb67Ew/edit?usp=sharing
Video Footage for your Reference
https://drive.google.com/drive/folders/1Ov9Dcfjhjab8QFFUGNBZDVtd4GPe1qkX?ths=true
Package included:
1 * SMO 4K Camera
1 * Spare Camera Bottom Cover
2 * SH1.0 4-Pin Power Cable
1 * Transparent UV Filter
1 * ND16 Filter
1 * Screwdriver
2 * Spare Screws for Camera Bottom Cover
1 * Pack of Camera Mounting Screws and Nuts
1 * User Manual
