CRIUS ARPDB 5.3V 3.5A 1MHz DC-DC PDB with BEC Support Max 28V 90A Type-A XT60 Type-B
Description:
Item Name: PDB
Optimization for AIO RACER F3 Flight Controller
Two types of optional, Type-A with XT60 mounting holes, Type-B is classic version
3 oz copper for high current
Max Input Voltage: 28V
Max Current : 90A
Switching regulator outputs 5.3V and 3.5A max
Fixing Hole: 30mm
Dimension:
Type-A: 48.2x35x4.7mm
Type-B: 35x35x4mm
Package Inlcuded:
Type A XT60:
1 x PDB
1 x 4P Cable
1 x XT60 Connector
Type B:
1 x PDB
1 x 4P Cable
