CYS BLS5818 12KG Brushless 90° Servo Full Metal Head Locking For 700 Class RC Helicopter - 66.00 €


CYS BLS5818 12KG Brushless 90° Servo Full Metal Head Locking For 700 Class RC Helicopter
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Description:
Brand:CYS
Item: BLS5818
Product: Brushless Servo
Operating Voltage: 6.0V-7.4V
Stall Torque: 10kg/cm(6.0V ), 12kg/cm(7.4V)
Operating Speed: 0.06sec/60degree(6.0V), 0.05sec/60degree(7.4V)
Stall Current: 3.0A/4.0A
No-load Current: 20mA/80mA(6.0V), 20mA/100mA(7.4V)
Control Signal: PWM
Neutral Zone: 1500usec
Reverse: 1000-2000usec
Dead Band: 2usec
Motor Type: Brushless
Gear: 25T Metal Gear
Bearing: Dual Bearing
Max Travel: 90°(each side 45°)
Wire Length: 300mm
Weight: 72g/PC
Dimension: 40*20*39.35mm
Application: For 700 Class RC Helicopter
Package Included:
1* CYS-BLS5818 Brushless Servo
