Specifications:
Brand Name: DJI
Item Name: Digital fpv system
| Air Unit | |
| Weight | Air Unit (Camera included): 45.8 g |
| 3.9 g (MMCX elbow each) | |
| Dimensions | Air Unit: 44×37.8×14.4 mm |
| Camera: 27.4×21.1×20.1 mm | |
| Coaxial Cable: 100mm | |
| Operating Frequency | 5.725-5.850 GHz |
| Transmitter Power (EIRP) |
FCC/SRRC: <30 dBm; CE: <14 dBm |
| Min. Latency (end-to-end) | Low Latency Mode (720p/120fps): <28 ms |
| High Quality Mode (720p/60fps): <40 ms | |
| Max. Transmission Distance | FCC/SRRC: <4 km; CE: <0.7 km |
| Video Format | MP4 (Video format: H.264; Audio format: ACC-LC) |
| I/O Interface | USB-C, MMCX, 3-in-1 port, microSD card slot |
| Supported Flight Control System | F3, F4, F7 |
| Operating Temperature Range | 32°to 104°F (0° to 40°C) |
| Input Power | 7.4-17.6 V, about 4-9 W |
| Channels | 8 |
| Channels Info |
FCC Channel 1: 5660 Channel 2: 5695 Channel 3: 5735 Channel 4: 5770 Channel 5: 5805 Channel 6: 5878 Channel 7: 5914 Channel 8: 5839 CE/SRRC Channel 1: 5735 Channel 2: 5770 Channel 3: 5805 Channel 8: 5839 MIC Channel 1: 5660 Channel 2: 5700 Channel 8: 5745 |
| Camera | |
| Sensor | 1/3.2'' CMOS; Effective Pixels: 4 M |
| Lens | 2.1 mm, f/2.1 |
| Shutter | Rolling shutter |
| ISO | 100-25600 |
| FOV | 150°(D); 122°(H); 93°(V) |
| Dimension | 22.1×21.1×20.1 mm |
| Weight | 8.2 g |
| Remote Controller mode2 | |
| Weight | 765 g |
| Operation Frequency | 5.725-5.850 GHz |
|
Max. Transmission Distance (Unobstructed, free of interference) |
FCC/SRRC: 4 km; CE: 0.7 km |
| Transmitter Power (EIRP) | FCC: <30 dBm; CE: <14dBm; SRRC:<19dBm |
| Operation Current/Voltage | 0.6 A @ 7.6 V |
| Operation Temperature | 0° to 40°C (32° to 104°F) |
| Charging Temperature | 5° to 40°C (41° to 104°F) |
| Remote Controller intelligent Battery (WM37-4920mAh-7.6V) | |
| Battery Type | LiPo 2S |
| Capacity | 4920 mAh |
| Voltage | 7.6 V |
| Energy | 37.39 Wh |
| DJI FPV Goggles | |
| Weight | Approx. 415 g (headband and antennas included) |
| Dimensions | 184×122×110 mm (antennas included), |
| 202×126×110 mm (antennas excluded) | |
| Screen Size | 2-inch × 2 |
| Screen Resolution (Single Screen) | 1440 × 810 |
| Screen Renew Rate | 120 Hz |
| Communication Frequency | 5.725-5.850 GHz |
| Transmitter Power (EIRP) | FCC/MIC: <30 dBm; CE: <14 dBm; SRRC: <19 dBm |
| Live View Mode | Low Latency Mode (720p 120fps) |
| High Quality Mode (720p 60fps) | |
| Video Format | MP4 (Video format: H.264) |
| Supported Video Play Format | MP4, MOV, MKV (Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3) |
| Operating Temperature | 32° to 104° F (0° to 40° C) |
| Power Input | 7.4-17.6 V |
| FOV | Adjustable from 30° to 54°. Adjustable image size from 50%-100% |
| Adjusting the Interpupillary Distance | 58 -70mm |
| Battery | 6.6V-21.75V External battery, total power consumption of 7W |
| Supported Storage Card | microSD cards with capacities of up to 128GB. |
