Eachine Caddx Joint Nebula Micro Edition 1000TVL 1.66mm FOV 165 Degree Analog Digital Camera 720P 60fps With Vista HD System 5.8GHz FPV Transmitter VTX AIO Combo KIT Compatible With DJI Unit FPV Googles - 48.00 €

Description:

Item Name: Eachine Airsight & Caddx Vista Como KIT

Version: Only Camera, Camera & VTX Combo (optional)

Vista KIT Weight: 26g(camera included)

Antenna Weight: 2.5g

Vista Dimension: 30x29x13mm

Camera Dimension: 19x19x20mm

Coaxial Cable: 120mm/80mm

Operating Frequency: 5.725~5.850GHz

Transmitter Power(EIRP): FCC/SRRC/MIC: <30dBm, CE: <14dBm

Max. Transmission Distance: CC/SRRC/MIC: 4km, CE: 0.7km

I/O Interface: USB-C,IPEX,3-in-1 port

Supported Flight Control System: F3,F4,F7

Operating Temperature Range: 0℃~40℃

Input Power: 7.4-26.4V

Power Output: 25mw/200mw/500mw/700mw

Hardware Included: Vista/Eachine Airsight/Coaxial cable/Antenna

Goggles: Work with DJI Goggles

Camera Specifications:

Sensor: 1/3" CMOS

Lens: 1.66mm

Shutter: Rolling Shutter

Wide Power Input: DC 5-36V

Weight: 6.5g

Analog Specifications:

Resolution: 1000TVL

Min. Latency: 4ms

WDR: Super WDR

OSD: Support

Menu: Support

Day/Night: Color/B&W

Image: 16:9 & 4:3 (switchable)

TV System: NTSC & PAL (switchable)

Digital Specifications:

Resolution: 720p/60fps

Min. Latency: 32ms

Image: 16:9

Features:

- Support anaglog and digital signals.

- Small size,stable and clear HD video.

- User can choose 25mw/200mw/500mw/700mw from DJI goggles setting.

- Allows up to eight drones to fly simultaneously.

- Support wirelessly connect Vista kit to the DJI FPV remote controller without having to purchase additional receivers.

Package Included:

1x Eachine Airsight Camera

or

1x Eachine Airsight Camera

1x Caddx Vista HD System FPV VTX

1x Coaxial Cable

1x Antenna

1x 5D-OSD Menu Board

3x FPV Silicone Cable (3-in-1 cable,2-pin,3-pin)

1x Screws Set

1x Manual
