Eachine EV800D 5 Inch 800*480 FPV Goggles + TX06 PAL 700TVL Mini FPV VTX Camera All in ONE Combo
EV800D Goggles Features:
Built-in with super HD DVR up to 720*576px resolution
Diversity RaceBand 40ch Auto-Searching
Two system (Display/Re cord duo core separated chipsets ) ensure no delay in displaying and no frame lost in recording(please use C10 super speed card to ensure the full frame recording)
Work friendly with p ilot-OSD, no block on the important flying OSD information;
Separable design, 5 inch screen can be used as small monitor on radio controller or with tripod;
HD high brightness 5 inch LCD specially tuned for FPV racing;
Diversity function, Built-in super sensitive 5.8GHz 40ch receiver module, with RaceRand;
Advanced auto-searching function and the working frequency show on screen;
Built-in 7.4V 1200mAh battery, each full charge offer 2 hours working time;
Wide range re-charge voltage 11-20V;
Accept 2S or 3S batteries as back-up power source, to prolong the working time;
Nice ergonomic design and fit different faces;
Super-wide visible angle up to 82 degree;
92% transparent lens adopted, no distort, no blur on the edge of screen;
Light weight 375g with 3.5 hr 1200mAh battery, RTF for any scale racing game;
5 Inch 800*480px HD high brightness LCD
TX06 AIO Camera Features
OSD configuration using FC Uart
Super small and lightweight
700TVL high picture quality,Low Power Consumption.
48CH channel with race band
Power by 1S lipo battery
Plug and play,designed for DIY
Super Mini 5.8GHz 48CH FPV Transmitter +700TVL FPV Camera+Brass dipole Antenna+OSD
Appearance | Dimension: 180*145*82mm Weight: 362g without antenna Belt : three-way adjustable belt |
Specification | Build in DVR R ecord up to 720*576px full frame rate video, no frame lost (C10 card required) Re play in MENU Require C10 card to r ecord full frame rate |
Diversity | -90dB Super sensitiveness in 2pcs RX5808 PRO modules Great performance when two types (Linear and Omni) antennas are used |
Display | Screen size: 5.0 inch Screen resolution: 800*480(No blur after enlarge by the lens) Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPV Ratio : 16:9, 4:3 View Angle: 140/120 degree(Horizontal/Vertical) |
Lens | 3x boost of the video to acquire intense feel-in-there video; 92% transparent rate distort if light; |
Battery | Built-in 7.4V/1200mAh battery; Each battery circle offer around 2hr working time; 10-22V wide range recharging voltage range, typical recharging voltage is 12V Charger : 12V,2A, DC 2.5mm 2S (7.4 V) /3S(11.1V) battery as back-up power t to have long working time. |
| Model : TX06 AIO Camera : Transmitting power: 25mW Frequency: 5.8G 48CH Input voltage:3.3-5.5V (recommanded battery click here) Current consumption:280mA(typical) Camera resolution: 700TVL Video Format: PAL Field of view : 120°viewing angle Antenna dimensions: 35mm*4.2mm diameter Antenna: Brass dipole Antenna Frequency:5.8GHz 6 bands 48 channels, with Race band:5474-5945MHZ Size: 14*13.8mm(L*W) Weight:2.8g |
Frequencies (5.8GHz, with RaceBand)
| CH | CH 1 | CH 2 | CH 3 | CH 4 | CH 5 | CH 6 | CH 7 | CH 8 |
| GROUP | ||||||||
| A or FR1 | 5865 MHZ | 5845 MHZ | 5825 MHZ | 5805 MHZ | 5785 MHZ | 5765 MHZ | 5745 MHZ | 5725 MHZ |
| B or FR2 | 5733 MHZ | 5752 MHZ | 5771 MHZ | 5790 MHZ | 5809 MHZ | 5828 MHZ | 5847 MHZ | 5866 MHZ |
| C or FR3 | 5705 MHZ | 5685 MHZ | 5665 MHZ | 5645 MHZ | 5885 MHZ | 5905 MHZ | 5925 MHZ | 5945 MHZ |
| D or FR4 | 5740 MHZ | 5760 MHZ | 5780 MHZ | 5800 MHZ | 5820 MHZ | 5840 MHZ | 5860 MHZ | 5880 MHZ |
| R or FR5 | 5658 MHZ | 5695 MHZ | 5732 MHZ | 5769 MHZ | 5806 MHZ | 5843 MHZ | 5880 MHZ | 5917 MHZ |
Package Included :
1 x EV800D 40CH 5.8G Diversity Goggles with DVR
1 x Clover Antenna
1 x Panel Antenna
1 x Battery Charger
1 x 3S to DC Power Cable
1 x User Manual
1 x Clean cloth
1 x Bag
1 x Eachine TX06 700TVL FOV 120 Degree 5.8Ghz 48CH Mini FPV Camera AIO Transmitter For RC Drone
1 x Molex 1.25mm to JST-DS 2.0mm 2P Power Cable
