Notice: If the monitor can't record the PAL format video or the image is not complete, please update it as follow:
1. Download the file: Upgraded File and put it in Root of TF card
2. Turn on the monitor, it will auto update as the video shows.
Notice: Before you use it, you should format your SD card to FAT32. There is a screen protector with H on screen, you can remove it.
LCD5802D Monitor
Description: User Manual
Brand Name: Eachine
Item Name: LCD5802D Monitor
Built-in 5.8Ghz Dual diversity receiver automatically for best reception
Built-in 2CH 5.8Ghz AV output and 1CH AV input
Built-in high performance Li-POLYMER Battery
Work status OSD display
A key to automatic signal search
Support Chinese and English menu
Format: JPEG, AVI
Screen size
Screen type
Resolution: 800*480
Brightness
View Angle:
Size
Working Voltage:
Power Consumption
Battery charging current
Working temperature
Connectors:RP-SMA female(outer needle)
Antennas Connectors:RP-SMA male (inner hole)
Support up to 32G , C10 SD Card.
Features:
With DVR function
Built-in Dual Receiver for best reception
Dual buffered AV outputs
Not affect by 2.4GHz R/C Radios
AV Receiver with Diversity inputs
Small, light weight, durable
5 Bands and total 40 Channels
Built-in battery , easy to carry and outdoor use
A key to automatic signal search
Work status OSD display
Notice: It can't receive 2 different channels at the same time
Band and Channel selection
| CH | CH 1 | CH 2 | CH 3 | CH 4 | CH 5 | CH 6 | CH 7 | CH 8 |
| GROUP | ||||||||
| A | 5865 MHZ | 5845 MHZ | 5825 MHZ | 5805 MHZ | 5785 MHZ | 5765 MHZ | 5745 MHZ | 5725 MHZ |
| B | 5733 MHZ | 5752 MHZ | 5771 MHZ | 5790 MHZ | 5809 MHZ | 5828 MHZ | 5847 MHZ | 5866 MHZ |
| C | 5705 MHZ | 5685 MHZ | 5665 MHZ | 5645 MHZ | 5885 MHZ | 5905 MHZ | 5925 MHZ | 5945 MHZ |
| D | 5740 MHZ | 5760 MHZ | 5780 MHZ | 5800 MHZ | 5820 MHZ | 5840 MHZ | 5860 MHZ | 5880 MHZ |
| R | 5658 MHZ | 5695 MHZ | 5732 MHZ | 5769 MHZ | 5806 MHZ | 5843 MHZ | 5880 MHZ | 5917 MHZ |
Antenna
Description :
Brand Name : Realacc
Item Name : Omnidirectional Antenna
Gain : 5dBi
Max. Power : 50w
Connector : RP-SMA
Color : Black, Red, White
Weight : 8.6g
Length : 78±3mm
Max. Dia. : 22.4±1mm
Min. Dia. : 11.8±1mm
Specification :
Frequency : 5.8G
Impedance : 50Ω
VSWR : <1.5:1
Polarization : Circular Polarized
Radiation : Omni
Features :
Omni-directional, no dead corner
High gain, more stable.
Less flash, stonger siginal
Package Included :
1 x 7" LCD Screen Receiver Monitor with built in Rechargable Battery
2 x Linear Antenna
1 x AV Cable
1 x Charger
1 x 7" LCD Screen Receiver Monitor with built in Rechargable Battery
2 x Linear Antenna
1 x AV Cable
1 x Charger
2 x RP-SMA Antenna
