Specification:
Brand Name: Eachine
Model: Tyro79S
Item Name: 140mm 3 Inch F4 FPV Racing Drone RTF
Version: RTF 2x Battery Version/ RTF 4x Battery Version ( Optional)
Receiver: Frsky XM+ Receiver
Flight Time: 4 mins ( Take example as 3s 650mAh Lipo)
| Tyro79 140mm Frame Kit | Brand Name: Eachine Model: Tyro79 Item Name: 140mm Wheelbase Racing Frame Arm Plate Thickness: 3mm Upper Plate Thickness: 1mm Side Plate Thickness: 1mm Material: 3K Carbon Fiber & CNC 6065 Aluminium |
| F4 OSD Flight Controller | Brand Name: Eachine Main Control Chip: STM32F411 Sensor: ICM20602 6-Axis Integrated OSD PPM/DSM/IBUS/UAR share: UART1-RX Mounting holes distance: 20x20mm Weight: 24g PID circulation rate and refresh rate can up to 32kHz Supports Betaflight/cleanflight/inav firmware |
| 20A BLheli_S 4In1 Brushless ESC | Brand Name: Eachine Continuous Current: 20A Burst Current: 25A (8S) BEC Output: NO Input voltage: 2-4S Main control chip: 48mhz EFM8BB2 - with 25V 150uF Capacitor ( Solder well on ESC Board) Firmware upgrade: Supports Dshot600/BLHeli_S/Oneshot125 MOS: 3*3 MOS Type: TPN2R703N Size: 27x31mm ( Mounting Hole: 20x20mm) Weight: 3.7g |
| 1607 2800KV 2-4S Brushless Motor | Brand Name: Eachine KV: 2800KV Lipo cell: 2-4S Weight: 17.8g (includes wires) Output shaft length: 14mm Maximum pull: signal 630g (4S 3030 4-blade propeller) Maximum power: 350W Configu-ration: 9N/12P Mounting holes distance: 12*12mm Mounting holes: ÏM2 Bearing: NSK N52 Strong NdFeB Magnet |
| Racerstar Tornado 3040 3-Blade Propeller | Brand Name: Racerstar Model: Tornado 3040 Item Name: 3040 3x4 3 Inch 3-Blade Propeller Material: PC Mounting hole: 5mm Center thickness: 5.5mm Quantity: 4 CW & 4 CCW Color: Transparent White Weight: 1.8g/PC |
| XF5805 5.8G 40CH 25/100/200mW VTX | Supports TBS SmartAudio Transmitting power:25/100/200/300mW switchable Channel: 40CH Full video format: NTSC/PAL Input voltage: 7V~24V Power dissipation: +12V/600MW; 260mA Size: 25Ã20Ã4mm Weight: â¤3.2g (except antenna) With copper pipe mini antenna (ipex antenna) Make sure the antenna is installed at the output end before powering up to avoid damaging internal components |
| Eachine 700TVL CMOS Camera | Case size: 19x19mm Weight: 9.5g Total pixels: PAL: 1020HÃ596V (0.61MP); NTSC: 1020HÃ508V (0.52MP) Effective pixels: PAL: 976HÃ582V (0.57MP); NTSC: 976HÃ494V (0.48MP) Signal system: PAL Resolution ratio(horizontal center): 700TVL Video output: 1.0Vp-p/75Ω Automatic gain control: 0.25/0.50/0.75/1.00, up to 55dB White balance: off Exposure mode: electron exposure Electronic shutter: 1/50(1/60) - 1/100000 S Gamma correction: 0.45/1.0 Synchronization method: inter-sync Camera lens: standard 2.1mm Lens operating voltage: DC 5-12V Working current: 70mA (low power consumption) Working temperature: -20â~-60â Humidity: 0%~98% |
| Frsky XM+ Receiver | Number of Channels: Up to 16CH from SBUS (1-15ch for PWM,16ch RSSI for FC) Operating Voltage Range: 3.7~10V Operating Current: 30mA @5V Operating Range: Full range With RSSI output on board: Analog 0~3.3V Firmware Upgradeable Compatibility: FrSky D16 mode Dimension: 21.5*12*3.5mm(L x W x H) Weight: 1.6g |
| LiteRadio Radio Transmitter | Brand Name: Eachine Model: LiteRadio Version: Mode 2 Frequency Range: 2.4G (2403MHz-2447MHz) 2.4G System: CC2500 Channel: 8 System: Frsky Protocol (D16/D8) Power: â¤80mw Model Type: Multi-rotor Support USB Charging Support FPV Simulator Connected Output: PPM, support Student Radio Mode LED Light: Green-Power On / Red-Warning / Blue-Normal Battery: 350mAh 2S Lipo Battery Weight: 227.4g (with battery) |
| 3S 11.1V 650mAh Lipo Battery | Brand Name: Eachine Item Name: 3S 11.1V 650mAh 45C 3S1P Lipo Battery XT30 Plug Size: 57x32x19mm (LxWxH) Weight: 55g |
Features:
- The drone builds and setup well out from factory
- with Battery, Receiver and Radio Transmitter, ready to fly
- Upgrade with TPU Part on the tail, more easier to install receiver cable and antena
- Upgrade with Racerstar Tornado 3040 3-Blade Propeller, more power and durable
Package Included:
2 Battery Version:
1x Tyro79S FPV Racing Drone
1x LiteRadio Radio Transmitter ( Mode 2 version)
2x Eachine 3S 11.1V 650mAh 45C Lipo Battery
1x 350mAh 2S Lipo Battery ( for Radio Transmitter)
1x B3 Pro Charger
4 Battery Version:
1x Tyro79S FPV Racing Drone
1x LiteRadio Radio Transmitter ( Mode 2 version)
4x Eachine 3S 11.1V 650mAh 45C Lipo Battery
1x 350mAh 2S Lipo Battery ( for Radio Transmitter)
1x B3 Pro Charger
