Eachine Vwhoop90 Brushless Tiny Whoop Tiny Whoov 2-in-1 FPV Racing Drone with Crazybee F3 700TVL Cam - 89.00 €

Eachine Vwhoop90 Brushless Tiny Whoop Tiny Whoov 2-in-1 FPV Racing Drone with Crazybee F3 700TVL Camera BNF

Description:

The world first Amphibian Drone is coming, it’s not only a tiny hovercraft , you can transformer it to a Tiny whoop and rush to the sky during Driving anytime. That’s more funny and awesome.

Specifications:
Brand: Eachine
Model: Vwhoop90
Item Name: 1S Brushless Vwhoop 2-in-1 FPV Racing Drone
Size:155mm*120mm*30mm
Weight:36g (without battery)
Fly Weight: 42.5g (with Original 3.8v 250mah Lipo battery)

SE0802 KV19000 Motor	Mode	SE0802 KV19000
	Configuration	9N12P
	Stator Diamter	8.4mm
	Stator Length	2mm
	Shaft Diameter	Φ1.0mm
	Motor Dimension(Dia.*Len)	Φ10.5mm*14.9mm
	Weight(g)	1.7g(without connector and cable)
	No.of Cells(Lipo)	1S
Servo	Weight	3.7g (Without connector and cable)
	Dimension	20.0x17.6x8.0mm
	Supply Voltage	4.8~6.0V
	Stall Torque	0.4kg.cm
	Operating Speed	0.12sec/60° (NO Load Running)
Flight Controller	Firmware	Betaflight_3.3.0_Crazybee
	Betaflight Target	CRAZYBEEF3FR (Frsky version) CRAZYBEEF3FS (Flysky version)
	MCU	STM32F303CCT6 (72MHZ, 256K FLASH)
	Sensor	MPU-6000 (SPI Connection)
	Board Size	28.5 * 28.5MM
	Board Weight	3.5g
	Power Supply	1S Battery Input (DC 3.5-4.35V)
	- Built-in 5A (each) Blheli_S 4in1 ESC Dshot600 ready - Built-in Frsky receiver with telemetry (D8/D16 switchable) - Built-in Betaflight OSD (SPI Control) - Built-in Current meter Max 14A - Built-in 5V 0.8A BEC with LC filter - Built-in voltage detection - BLHELI_S pass-through Ready - Heading LED Ready
Onboard 4-in-1 5A ESC	Power Supply	1S LiPo/LiPo HV (4.2v/4.35v)
	Current	5A continuous peak 6A (3 seconds)
	Factory Firmware	O_L_5_REV16_6.HEX
	Default Protocol	DSHOT600
	Support BLHeliSuite programmable
Frsky Receiver Version	Channels	8ch or 16ch
	No ground interference ( Transmitter and receiver 1m from the ground)	300m
	- SPI BUS receiver - Frsky D8/D16 switchable - Compatible both D8 and D16 transmitter - Failsafe support
Flysky Receiver Version	Protocol	AFHDS and AFHDS-2A Switchable
	Channels	8ch(AFHDS) or 14ch(AFHDS-2A)
	No ground interference ( Transmitter and receiver 1 m from the ground)	300m
	- SPI BUS receiver - Failsafe support
AIO Camera & VTX	Output Power	25mw
	Frequency	48CH
	Input Voltage	3.3V 5.5V
	Current Consumption	300mA (type)
	Camera Resolution	700TVL
	Field of View	120°
	Video Format	NTSC
	Antenna	RG178 Antenna
	Frequency	5.8GHz 6 bands 48 channels
	With Race Band	5474 5945 MHZ
	Size	13.9"12.0mm ( L*W )
	Weight	3g
Lipo Battery	Capacity	250mAh
	Voltage	3.8V
	Continuous Discharge Rate	30C
	Instantaneous Discharge Rate	60C
	Size	60mmx18mmx7mm
	Weight	6.5g
	Connector	PH2.0

Package Included:
1 x Vwhoop90 Frame
1 x Crazybee F3 Flight controller (Option Frsky or Flysky or DSM)
4 x SE0802 KV19000 Brushless Motor
1 x 5.8G 25mw 40ch VTX&Camera
1 x Servo
4 x Propeller
3 x 3.8v 250mah 30C/60C Lipo Battery
1 x USB Charger
