FrSky R9M 2019 900MHz Long Range Transmitter Module and R9 Slim+ OTA ACCESS RC Receiver with Mounted Super 8 and T antenna
â
âOVERVIEW:

R9M 2019 900MHz Module	R9 Slim+ OTA Receiver
FrSky R9 and R9M radio control system is the first FrSky long range system which works in the frequency of 900MHz. The R9M module offers 4 switchable RF power outputs to so you can choose the appropriate power for different flight situations. Compared to another FrSky 2.4GHz long range receiver like the L9R, the R9 receiver has a longer operating range up to 10KM and above. Moreover, the R9 is also a redundancy receiver which can connect to another receiver to ensure the security of your aircraft.	The R9 Slim+ OTA is designed with dual antennas to improve signal strength. With a compact form factor design, it also features 6 PWM outputs, and this long range receiver with the flexibility to work with more external devices by incorporating the inverted SBUS and S.Port outputs.â	The 900MHz R9 Slim+ OTA receiver implements the ACCESS protocol and supports wireless firmware updates over the air making binding to receivers even easier. As well as the convenience of checking the current receiver firmware version.

Specification:
Brand Name: FrSky

Item Name: R9M Module and R9 Slim+ OTA Receiver
Weight: 150g

R9 Slim+ OTA Receiver:

Dimension: 32*13.5*5mm (L Ã W ÃH)

Weight: 4.3g (with antennas)

Numbers of channel

Non-LBT Version: 6/16CH (Telemetry)

LBT Version: 6/16CH (Telemetry) / 6/16CH (No Telemetry)

With RSSI Output : Analog 0~3.3V

Operating Voltage Range: DC 3.5V~12.6V (1~3s Li-Battery)

Operating Current: 100mA@5V

Operating Range: up to 10km or above

Compatibility: R9M Lite/R9M/R9M 2019 with ACCST firmware,

R9M Lite/R9M Lite Pro/R9M 2019 with ACCESS firmware
â
ACCESS Protocol and support OTA functions

Low latency and high precision

Support S.Port / F.Port (Configurable in OpenTX / FrOS menu)

With inverted SBUS and S.Port outputs

Battery voltage detection supported

Detachable Ipex1 connector antenna

â
R9M 2019 900MHz Module:

Compatibility : R9 series

Vin Voltage Range: 6.5V-13V

External Power Supply: 6.5V~13V

Telemetry Interface: Smart Port

Upgrade Interface: Smart Port

Modulations: PXX or CPPM (auto-detected)
â
â900MHz/868MHz working mode

Long range, low latency and high precision RC system

4 Optional RF power (Non-EU Version)

Telemetry modeï¼25mWï¼/non-telemetry modeï¼200mW / 500mWï¼ (EU Version)

RF Power (Flex): 10mW/ 100mW/ 500mW/ 1W (telemetry supported for all levels)

Smart Port enabled and support telemetry data transmission

â
Package Included:
1 x R9M 2019 module with mounted Super 8 antenna

1 x R9 Slim+ OTA receiver with mounted Ipex1 T antenna
