Goteck DC1612SG 12kg Standard Digital Coreless Servo with High Speed Brushless Motor for RC Helicopter Car Robot - 39.00 €


Goteck DC1612SG 12kg Standard Digital Coreless Servo with High Speed Brushless Motor for RC Helicopter Car Robot
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Specification:

Control System:Positive PWM control (1500 usec Neutral)

Operation Voltage Range:4.8V ~ 6.0V

Operation Temperature Range: -20C°~ +60C°

Test Voltage: At 4.8V At 6.0V

Torque:10kg.cm /12kg.cm

Idle speed :0.09sec / 60 deg 0.07sec / 60 deg

Idle current:350mA/400mA

Running Current:3000mA/3400mA

Death band width:1 usec

Circle>15000 times/idle load

Operation travel:55°±5°

Direction :Anti-clockwise/ Pulse Travel 1500 to 2100 usec

Drive type:FET drive

Motor type:Coreless

Potentiometer type:Indirect drive

Amplifier type:Digital

Size:40*20*37.2mm

Weight :53g (without accessories)

Ball bearing Double ball bearing

Gear material:Import steel gear

Case material:Nylon plus fiber/ Aluminum medium

Connector Wire Length:300mm

Connector Wire Gauge:22AWG,JR Universal

Brown:Negative

Red:Positive

Orange:Signal

Application:Car model; fixed-wing;aircraft; helicopter; robot.


Package Included:

1XDigital Coreless Servo
