Specification:
Brand Name: HAKRC
Model: LEDF4 & 1S10A
Item Name: F4 OSD Flight Controller & 10A BLheli_S 4in1 ESC Flytower
Dimension: 25x22x11mm
Mounting Hole: 16x16mm, M2
Weight: 6g
LEDF4 Flight Controller
CPU: STM32F411C
Gyro: MPU6000
Input Voltage: 1S Lipo
Integrated with LED_Strip, OSD
Built-in LC Filter
Support BF firmware ( HAKRC F411 firmware)
Application: for frame kit less than 70mm.
Receiver Setting:
DSM2/DSMX, SBUS, IBUS Receiver, Set RX1
PPM Receiver, don't need choose UART Port.
1S10A BLheli_S 4in1 ESC
Con. Current: 10A
Peak Current: 12A (5S)
BEC: 5V @ 1A
Input Voltage: 1S Lipo / HV-Lipo
Firmware: BLHeli_S O_L_05_REV16_7
Support Dshot150 Dshot300 Dshot600 Oneshot125 Multishot and PWM
Package Included:
1x LEDF4 Flight Controller
1x 1S10A 4in1 ESC
2x Cable
1x bag of Screws
