HAKRC 20x20mm Omnibus STM32F405 F4 Flight Controller AIO OSD 5V BEC Blackbox for Mini Drone
Note: Only package including the F4 FC.
The ESC was not included.
Specification:
Item name: 20x20mm Omnibus F4 FC AIO OSD BEC
Size: 27*27mm
Mounting hole: 20*20mm , M2.5
Weight: 8.5g
Processor: STM32F405RGT6
Sensor: MPU-6000 (connected by SPI)
Firmware version: betaflight_3.1.0_OMNIBUSF4
Built-in BEC: 5V/1A
Power supply: 2-4S lipo battery
Usage: for ≤ 280mm wheelbase frame
specially for ≤130mm frame
for bulding 20x20mm Flytower with 15A 4 In1 ESC
Features:
Usage: for ≤ 280mm wheelbase frame
specially for ≤130mm frame
for bulding 20x20mm Flytower with 15A 4 In1 ESC
Features:
- Support PPM/SBUS/DSM2/DSMX Receiver; 3.3v Spektrum Satellite Receiver
- with LED_STRIP solder pin
-with Buzzer solder pin
-With LC filter
-With 128Mb flash (16M Byte)
-Built-in OSD (Using F4 MCU controls OSD over SPI bus in DMS mode)
-Built-in voltage detection, alarm
-Support the newest DSHOT ESC
-Support programmable LEDSD (turn off transponder before using)
-Support BLheli suite
Notice for Setting up receiver:
Notice for Setting up receiver:
-DSM, SBUS receiver input, please configuire RX1 as input interface.
-DSM receiver power from 3.3V.
-SBUS and PPM receiver power from 5V.
Package Included:
1x HAKRC Omnibus F4 Flight Controller
