Specification:
Brand Name: HGLRC
Model: FD765-VTX
Item Name: F7 Flight Controller & 65A 4in1 ESC & 48CH VTX Stack
Stack Height: 30mm
Mounting Hole: 30.5x30.5mm
Stack Weight: 48.2g
FD F7 Flight Controller AIO OSD BEC
Item Name: Dual Gyroscope F7 Flight Controller
MPU: ICM20608 (32K) & MPU6000-SPI
CPU: STM32F745VGT6, 32K+16K
Input Voltage: 3-6S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A, [email protected]
LED Output: 5V@3A,
Size: 37x37mm, 30.5mm mounting holes
Weight:10.2g
FD 65A L431 BLHeli_32 3-6S 4in1 ESC
CPU:STM32L431
BLHELI32 Firmware
Input Voltage: 3-6S Lipo
Steady Current: 65A
Peak Current: 75A
BEC: NO
Supported Protocols: DSHOT1200/600/300/150.ONESHOT125/42.MultiShot
Size: 46*45*6mm
Weight:23.8g
FD VTX
Output power: PIT/25mW/50mW/100mW/200mW/400mW
Control mode:BFOSD control(RX) / button
Input: DC 7-28V
BEC:5V-1A
Video system: NTSC/PAL
Antenna: MMCX
Connector: RP-SMA Male
Frequency: 5.8GHz 6 bands 48 channels.with Raceband: 5362-5945 MHZ
Size:36x36x5mm.Hole:30.5*30.5mm
Weight: 5.2g
Package Included:
1x FD F7 Dual Flight Control
1x FD 65A L431 Blheli_32 3-6S 4in1 ESC
1x FD VTX
