Specification:
Brand: IDC-RF
Item Name: 397TX Digital VTX Transmitter Modul
Size: 38*45*9mm
Weightï¼1g
| Working Temperature | -10~(+)60â |
| Transmission Power | 318mAï¼Pout=22dBmï¼ |
| Acceptance Sensitivity | -89dBmï¼Typicalï¼ |
| Modulation Mode | FSK/GFSK |
| Working Current | 4 μA |
| Voltage | 3.3-5V |
| Working Frequency | 2400-2483.5MHz |
| Programmable Transmitted Power | 22dBm~26dBm |
| Programmable Transfer Rate | 2Mbps~6Mbps |
Features:
1. 2.4G frequency hopping spread spectrum (FHSS) digital radio frequency technology, intelligent frequency hopping (automatically changing the RADIO frequency channel) to avoid interference from other 2.4GHz devices, such as WLAN, microwave, cordless phones.
2. Transmission Distance: 50m (line of sight), height: 200m
3. CE 300 328 and FCC 15.247 Certification
4. Mean Delay Time < 120 ms.
5. Paired encryption, each customer has a separate ID, video encryption transmission.
Package Includedï¼
1 X IDC 397TX Digital VTX Transmitter Module
