Specification:
Brand name: iFlight
Item name: TurboBee 66R 1.2 Inch 1-2S Whoop FPV Racing Drone
Brushless Motor: iFlight BeeMotor 0802 12000KV 1-2S
Flight Controller & ESC: SucceX F4 Whoop Flight Controller 2-4S 12A AIO Board
VTX: SucceX Whoop-VTX 25/100/200mW
Camera: Caddx.us Turbo Eos2 2.1mm 16:9 NTSC Cam
Weight: 42.9g
SucceX F4 Flight Controller |
-STM32F411 -Input voltage 2-4S -Gyro: ICM-20689 -2x UART ports -OSD inbuilt
-Baro -Blackbox FLASH 8MB -BEC 5V 2A Cont. -Size:28.5*28.5mm -Mounting holes:φ3mm 25.5*25.5mm -Weight: 6.1g -BF target : IFRC/IFF411PRO(STM32F411)
-Current scale |
SucceX Micro 12A ESC |
-Firmware: BlheliS G-H-30 -Input voltage : 2-4S -Continuous current: 12A -MCU: BB21F16G -BEC: None -ESC protocol: PWM, oneshot125, multishot, dshot150, 300, 600, etc. |
SucceX Whoop VTX |
-Power: PIT/25/100/200mW -Antenna interface: IPEX (UFL) -Telemetry: IRC Tramp -Size: triangle 26mm*19mm -Mounting holes: none -Weight: 2g |
Package Included:
1 x TurboBee 66R Frame Kit
1 x SucceX F4 Whoop Flight Controller 2-4S 12A AIO Board
1 x SucceX Whoop-VTX 25/100/200mW VTX
4 x BeeMotor 0802 12000KV 1-2S Brushless Motor
1 x 5.8Ghz ipex UFL Plug Antenna
1 x Caddx.us Turbo Eos2 Camera
1 x iFlight 30mm Duct set
2 x 10*100mm Battery Strap
1 x XT30U Male with cable wire
4 x HQ 30mm 4-blade 1mm Hole Balck Propeller CW
4 x HQ 30mm 4-blade 1mm Hole Balck Propeller CCW
1 x 14mm Black Camera Mount TPU 3D Printed Parts ( 1 Pair )
1 x VTX Buckle TPU 3D Printed
1 x Antenna Bracket TPU 3D Printed
1 x Receiver Mount TPU 3D Printed
2 x Black Small Antenna Protection Cap
2 x Black Small Antenna Protection Tube 4CM
