JJRC JJPRO-P130 FPV Quadcopter with NAZE32 FPV 800TVL Camera 5.8G 25mW 40CH Transmitter ARF/ RTF
Note:The color of Frame Kit is the same as those of propeller
Description:
Brand Name: JJRC
Item Name: JJPRO-P130 Racing Drone
Model: P130
Motor(User Manual)
Model: X1806-16T
KV: 2300
MAX Thrust: 200-350G
Max. Current: 13A
Lipo(S): 2-3S
Height: 21.5MM
Diameter: 23MM
Propeller: 3 inch(3045)
Weight: 17G
ESC(User Manual)
Brand: Flycolor
Model: Fairy-12A
Continuous Current: 12A
Instantaneous Current(10S):18A
BEC: 5V/1A
Input Voltage: 2-4S
Weight: 9.5G
Size(without plug): 28x15x6mm
Typical Applications (for reference): 200-330 Multi-rotor
Transmitter(User Manual)
Brand: Flysky
Model: FS-i6
Channels: 6 Channels
Model Type: Glider/Heli/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF Power: Less Than 20dBm
2.4ghz System: AFHDS 2A and AFHDS
Code Type: GFSK
Sensitivity: 1024
Low Voltage Warning: less than 4.2V
DSC Port: PS2;Output:PPM
ANT length: 26mm*2(dual antenna)
Weight:392g
Power: 6V 1.5AA*4
Display mode: Transflective STN positive type, 128*64 dot matrix VA73*39mm,white backlight.
Size: 174x89x190mm
Color: Black
Model Memories: 20
Receiver:
Model: FS-iA6
Channel: 6CH
Model type: fixed-wing/ glider/ helicopter
RF receiver sensitivity: -105dBm
Modulation: GFSK
System type: AFHDS2A /AFHDS
Channel resolution: 1024 steps
Bind port: yes
Power port: yes(VCC)
Power: 4.0-6.5V DC
Flight controller
Model:NAZE32
Size: 3.6cm*3.6cm
Weight(wiht line): 11G
Camera
Operating voltage: 3.6-5.5V
Image Sensor: 1/3” CMOS
Resolution: 800TVL Lens
Angle: 150° FOV horizontal angle
170° DFOV opposite view angle
Current: 100mA
Wireless channel: 40 CH
Sound carrier: 6.5 MHz
Signal System: NTSC/PAL(One key switch)
Power Consumption:380mA@3·7V
Output impedance: 750 hm
Operating signal intensity: 23-24dBm
Lens Diameter: 2.1mm IR coated FOV150°
Size: 18.5mm*16.5mm*8mm
Image Transmission
Signal System: NTSC/PAL
Output Impedance: 75 Ohm
Intensity of the output signal: 12-14dB
Output Power: 25mW
Wireless Channels: 40CH
Operating Voltage: 2·7-5·5v
Power Supply: [email protected]
Size: 18mmX16.5mmX8mm(without antenna)
Weight: 6.8G
Package Included:
ARF Version:
1 x JJPRP P130 Frame Kit
4 x X1806 2300kv Motor
4 x 12A ESC
8 x Propellers
1 x NAZE32 Flight controller
1 x Section Board
4 x LED Lights
1 x 5.8G Image Transmitter(with CMOS 800TVL Camera)
1 x 11.1V 850mAh Battery
1 x Screwdriver
RTF Version:
1 x JJPRP P130 Frame Kit
4 x X1806 2300kv Motor
4 x 12A ESC
8 x Propellers
1 xNAZE32 Flight controller
1 x Section Board
4 x LED Lights
1 x 5.8G Image Transmitter(with CMOS 800TVL Camera)
1 x 11.1V 850mAh Battery
1 x Screwdriver
1 x FS-i6 Transmitter/Receiver
