Introduction:
The Jumper SF series of receivers offer a high quality yet affordable S-FHSS solution for modelers.
The SF Series can be used as a standard PWM receiver or in S.Bus mode for drones
or fixed wing craft, robotics, boat or anything that uses an advance control system requiring S.Bus input.
The SF series are a full range receiver featuring dual antennas for diversity reception.
When reliable quality receivers can be had at this price why risk any alternative!
Specification:
Brand Name: Jumper
Item Name: 2.4G 4CH Full Range SFHSS FHSS Receiver
Model: SF410
Working Voltage: 3.6~7.5V
Working Vurrent: 45~60mA
Working Temperature: 0-70 °C
Delay: Normal Mode 13.6mS
Special Mode 20.4mS
Effective Distance: >1.8km
Weight: 5.6g
SBUS: Yes
Full Range: Yes
Dual Diversity Antenna: Yes
Application: Compatble with Jumper T8SG/T8SG v2/T8SG v2 Plus/T8SG Lite/T12
Futaba T4YF/T6J/T6K/ T8J/T10J/T14SG/T18MZ/T18SZ
Ground System 3PL/ T3PRKA/ 4PLS/ T4PX/ T4GRS.
Bind/Pair procedure:
1. Turn on your transmitter and select S-fhss if it is necessary,
2. Press and hold the bind button on the receiver and power on the receiver,
3. When the LED turns on solid green, bind finish.
4. Then you can connect servos to each channel and check for correct function from stick and switch movement on your radio.
PWM output mode and Sbus output mode Setting
PWM Mode (normal mode): All channels will output PWM. All SF series receivers are set to PWM as default.
S.bus Mode (Special mode): The last channel of the receiver will output S.bus. All other channels will output PWM.
How to change modes?
- Turn off your transmitter, the LED will be red,
- Hold and press the bind button for 6 to 0 seconds,
- Then release the button and the red led will flash fast,
- Press the bind button quickly once to confirm while the red led is still flashing.
Notice:
The SF series receivers have a failsafe mode similar to original Futaba Receivers.
Before flight, we strongly recommend that fail safe modes are correctly setup on your receiver.
Package Included:
1x Jumper SF410 Receiver
