JX Servo C60 8.4V 60KG 180° Coreless Metal Gear Large Torque Digital Servo For RC Models - 89.00 €

JX Servo C60 8.4V 60KG 180° Coreless Metal Gear Large Torque Digital Servo For RC Models
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Description:
Brand: JX Servo
Item: C60 Digital Servo
Pulse width:1000-2000μs=90°
Pulse width:500-2500μs=180°
Dead band: 2μs 1520μs / 330hz
Motor: Coreless Motor
Voltage: 6.0-8.4V
Operating Speed (6.0V): 0.13sec/60°
Operating Speed (7.4V): 0.12sec/60°
Operating Speed (8.4V): 0.11sec/60°
Stall Torque (6.0V): 52kg.cm
Stall Torque (7.4V): 55kg.cm
Stall Torque (8.4V): 62kg.cm
Connector Wire Length: JR 265 mm
Bearing: 2BB
Weight: 87g
Dimensions:40X20X43.3mm
Application: For RC Models
Package:
1* JX Servo C60 Digital Servo
1* Servo Arm Set
