Kingkong 210GT 210MM FPV Racer Quadcopter RTF with CCD Camera 5.8G 600mW VTX Flysky i6 Transmitter
Description:
Brand Name: Kingkong
Item Name: 210GT RTF
Thickness of Upper Plate: 1.5±0.2mm
Thickness of Bottom Plate: 3±0.2mm
Flight Controller: Micro CC3D, Micro F3
Propeller: 5040
Motor: 2205 2300KV(2-4s)
ESC: BLHELI 20A 2-4s
VTX: 600mW 5.8G
Antenna: RHCP, SMA
Remote Control System: Flysky FS-i6
Battery: 3S 1300mAh 25C Battery
Frame Weight: 306g
20A ESC
Processor: MEGA88A(16Mhz)
Rated Voltage: 2S-4S LiPo
Continuous Current: 20A
Instantaneous Currents: 25A(Max. 5 seconds)
BEC: No
Aluminium Radiator Fin: No
Size: 25 x 12 x 3mm
Net Weight: 4g
700TVL CCD Camera
Format: PAL,NTSC
View Angle:115°
Lens Type: F2.0/2.8MM
Voltage: DC8V-18V
Weight: 16.4g
5.8G 600mW 32CH VTX
Video Format: NTSC/PAL
Voltage: 5v
Transmitting Power: 600mW
FS-i6 Specifications:
Channels: 6 Channels
Model Type: Glider/Heli/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF Power: Less Than 20dBm
2.4ghz System: AFHDS 2A and AFHDS
Code Type: GFSK
Sensitivity: 1024
Low Voltage Warning: less than 4.2V
DSC Port: PS2;Output:PPM
Charger Port: No
ANT length: 26mm*2(dual antenna)
Weight:392g
Power: 6V 1.5AA*4
Display mode: Transflective STN positive type, 128*64 dot matrix VA73*39mm,white backlight.
Size: 174x89x190mm
On-line update:yes
Color: Black
Certificate: CE0678,FCC
Model Memories: 20
Channel Order: Aileron-CH1, Elevator-CH2, Throttle-CH3, Rudder-CH4,Ch 5 & 6 open to assignment to other functions.
FS-iA6 Specifications:
Channels: 6 Channels
Model Type: Fixed-wing/Glider/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF power:less than 20dBm
RF.receiver sensitivity:-105dBm
2.4ghz System: AFHDS 2A
Code Type: GFSK
ANT length: 26mm
Weight:6.4g
Power:4.0-6.5V
Size: 40.4x21.1x7.35mm
Color: Black
Certificate: CE,FCC
i-BUS port: NO
Data Acquisition port:NO
Features:
3mm carbon frame body,strong,light-weight frame
20A 2S-4S Opto BLHeli Speed controllers
Powerful KINGKONG 2300kv motors
Pre-tuned micro CC3D flight control system
CCD camera has good effect at night flight.
Standard camera holders, the vertical angle is adjustable
High brightness multicolor rear LED with lampshade
Package Included:
1 x 210MM Frame Kit
4 x 2300KV Motor
4 x 20A ESC
20 x 5040 Propeller
1 x 600mW 5.8G VTX
1 x 700TVL CCD Camera
1 x SMA RHCP 5.8G Antenna
1 x 3S 1300mAh Battery
1 x Battery Charger
1 x Flysky i6 Transmitter
1 x Flysky iA6 Receiver
