MAMBA F405 DJI Betaflight Flight Controller F50 50A 3-6S DSHOT600 FPV Racing Brushless ESC Stack - 62.00 €

MAMBA F405 DJI Betaflight Flight Controller F50 50A 3-6S DSHOT600 FPV Racing Brushless ESC Stack

Specification:

MAMBA F405 DJI FC
MCU: STM32F405RGT6
Frequency: 168MHz
IMU: MPU6000
OSD: AT7456E
Blackbox: 16M Memory
Uarts: 6 Set
Receiver: TBS/PPM/SBUS/IBUS/DSM
RSSI Pad: Yes
Buzzer Pad: Yes
CURR Pad: Yes
Motor: 4 Set
BEC 3.3V: Yes
BEC 5V: Yes
BEC 9V: Yes
MB LED: Yes
BF LED: Yes
Bluetooth: NO
Input: 6S Lipo
VTS Protection: Yes
Soft: Betaflight
Target: MAMBAF405US
Mounting: 30.5×30.5mm,⌀ 3
Size: 38.0×38.0×7.0mm
Weight: 7.5g

F50 50A Blheli_S 3-6S DSHOT600 ESC
Output current: 50A
Peak current: 55A
Input: 6S Lipo
Blheli_S
CURR: Yes
Telemetery: NO
BEC: NO
Target: CH40
Dshot: Dshot 300/600
Mounting: 30.5×30.5mm,⌀ 3
Size: 45.0×41.0×6.5mm
Weight: 15g

Diagram
HD Download
https://www.diatone.us/apps/help-center

Package Included:
1 x MAMBA F405 DJI Flight Controller
1 x F50 50A Blheli_S 3-6S DSHOT600 ESC
