Description:
FOV:120 degree
CCD type: 1/3 960H CCD
Total pixels: PAL: 1020H * 1980V (5 million images) / NTSC: 1020H * 1980V (5 million images)
Active pixels: PAL: 1020H * 1980V (5 million images) / NTSC: 1020H * 1980V (5 million images)
Signal system: PAL/NTSC
Resolution (horizontal center): 700TVL
Digital noise reduction: 2D digital noise reduction (2DNR) supports 0~15 level 16 adjustable
Minimum illumination: 0.01LUX/F1.2
The signal-to-noise ratio: ≥48dB
Video output amplitude: 1.0Vp-p/75Ω
Automatic gain control: 0.25/0.50/0.75/1.00, four grades can be adjusted, the maximum can reach 55dB
White balance: open / close selectable
Backlight compensation: high brightness backlight compensation (HLC) / backlight compensation
Exposure mode: electronic exposureElectronic shutter: 1/50 (1/60) - 1/100000 seconds
Gamma correction: 0.45/1.0
Synchronous mode: internal synchronization
Audio: no
Operating voltage: DC12V±5%
Operating temperature:-20â--60â
Humidity: 0% ~ 96%
Lens thread: M12"
Size: 25mm*25mm
Weight:20g
Features:
Light weight and good quality.
Package included:
1 x Mista FPV Camera
1 x Cable
1 x Replacement shell
4 x Screws
