OD 12.5mm 12 Loop 2A Micro Conductive Slip Collecting Ring Rotor For 12MM Gimbal Motor RC Drone
Description
Out Diameter:12.5mm
Length:25mm
Weight:8g
Wires:12
Specification
Speed : 250rpm
Current Loop : 12 Max.2A/each
Voltage : 240VDC/VAC
Current : 1.5-2A
Working Temp. : -20â~60â
Wire Specification : UL,AWG30
Wire Length : 200mm
Compressive Strength : â§500VDC@50Hz
Compressive Resistance : 1000MΩ@500VDC
Electrical Noise : min. 10mΩ
Working Life : â§5 million spins(depends on the speed&environment)
Package Included (motor is not included)
1 x Gimbal slipring
