Brand : RunCam
Item name : hybrid
Color : Black
Color : Black
Parameters :
| HD sensor | SONY 8MP |
| Analog sensor | SONY 1.3MP |
| Field of View (FOV) | HD Recording FOV 145°(FPV FOV: 150° @ 4: 3) |
| Video Resolution | 4K@30fps / 2.7K@60fps / 2.7K@50fps / 1080P@120fps / 1080P@100fps / 1080P@60fps / 1080P@50fps |
| Video File Format | MP4 |
| TV Mode | NTSC (720*480)/PAL (720*576) Switchable |
| Interface | HD supports UART remote control; Analog supports UART fimrware update. |
| Max Micro SD CardSupported | Up to 128G. U3 recommended (2.7K60/1080P120 requires U3 or above; other solutions require U1 or above) Please make sure that the file format of the SD card is FAT32, otherwise, it will easily cause errors. |
| Mounting Hole Distance | 20*20mm |
| PCB Size | 29*29mm |
| Lens Module Size | 19*25mm |
| Lens Specs | HD M10 ; Analog M8 |
| Power Input | DC 5-20V (Non-direct power supply from 4s battery or above. Powered direcly with battery will generate surges and burn the camera.) |
| Working Current | 480mA @5V / 140mA @12V |
| Weight | 18g |
Features :
-True 145° HD Recording & 6ms FPV Latency
-Single board Supporting Start/Stop Recording via UART Control
-HD Recording supports QR Code Setup Analog FPV supports Firmware Update
Package:-Single board Supporting Start/Stop Recording via UART Control
-HD Recording supports QR Code Setup Analog FPV supports Firmware Update
1x RunCam hybrid Camera
1x Plastic cover
1x Plastic cover
1x 3PIN FPV silicone cable(male)
1x 3PIN FPV silicone cable(female)
1x Set of M2 screws
