SIYI FM30 2.4GHZ 30KM Telemetry Bluetooth Long Range Transmitter Module UART SBUS PPM Input with FR/FR Mini OTA Receiver for RC Drone
OVERVIEW:
30KM Radio Module with Datalink, Telemetry, and Bluetooth
FM30 is based on SIYI Tech's industry-level radio frequency technology, accu-mulated for years. The built-in Bluetooth function supports outdoor wireless FC settings and real-time flight status monitoring. The module is tiny and compatible with standard JR slot. FM30 also supports multiple signal input and commu-nication protocols, users will have an unprecedented experience of manipulating
their model craft, exploring range limits, and having fun.
Description:
Brand Name: SIYI
Item Name: FM30 Module with FR/FR Mini Receiver
Model: FM30
Module Weight: 36g
FR Receiver Weight: 20g, FR Mini Receiver Wight: 1.5g (Both without Antenna)
Frequency: 2400- 2483 MHz
Transmission Distance: >30 km(unobstructed, free of interference)
Latency: 10 ms(protocol mode)
Signal Input: UART, S Bus, PPM
Channels: 16 CH
Antenna Connector: SMA Female
Power Input: 5-8.4V
Power Consumption: 0.7W
Firmware Update: Supported
Product Dimension: 70 20*33 mm
Compatible Slot Size: 59"4318.5 mm
Working Temperature: -10-55°C
Features:
30KM Long Range
Aplied with lately developed technologies, such as super long distance, self-adaptive bandwidth, interference avoidance frequency hopping, and two-way telemetry, equipped with industry-level RF hardware which is capable to counter high power electromagnetic interference, FM30 radio module s maxi-mum control distance can reach up to 30 kilometers and more, which can effectively guarantee the low-altitude manipulating stability crossing among tres, through racing panels, in garage and other concrete buildings with many obstacles, shelters, and heavy interference.
Bluetooth/Telemetry Configuration
FM30 comes with built-in Bluetooth function and supports Mavlink protocol, which makes it possible for users to monitor real-time flight status and do configuration through the ground control software
-FM30 supports popular GCS such as QGroundControl, Speedy Bee, Mission Planner, Fish Drone, etc.
Receiver oTA Wireless Upgrading, Wireless Binding
The way of upgrading receiver firmware wirelessly let users get rid of complex wire connection.
Through a combination of manipulation, receiver actively enters binding mode without disassembling your drone/aircraft.
RSSI Signal Telemetry
FM30 supports RSSI output in S.Bus mode, providing real-time status information as reference for long-range flight.
2. 4 GHz ISM Frequency Band
FM30' s uses 2.4GHz band, which is legal to use in any countries. Under 2.4GHz and working with Fast Hopping techology, FM30's transmission speed is fast and stable.
Coming Soon:
USB Simulator
Wireless Master-slave
Multi-drone Control
RC Relay
Package Included:
1 x FM30 Module
1 x FR/FR Mini Receiver (Optional)
1 x USB Cable
