Specification:
DC Input Voltage : 11-18V
AC Input Voltage : 100-240V
Display Type: 2X16 LCD
Case Material: Plastic
Controls: Four Buttons
Case Size: 135x110x60mm
Weight: 390g
External Port: 1-6S Balance Socket-XH, Temperature Probe Socket.
Battery Socket, DC Input
Detection for NiMH/NiCd: 3-15mV/cell / Default: 4mV/cell
Battery Cutoff Temperture: 20â/68â-80â/176â(adjustable)
Charge Voltage: LiPo: 4.18-4.25V/cell Lilon: 4.08-4.2V/cell
LiFe: 3.58-3.7V/cell LiHV: 4.25-4.35V/cell
Balance Current: 300mA/cell Max
Reading Voltage Range: 0.1-26.1V/cell
Battery Types/Cells: LiPo/Lilon/LiFe/LiHV: 1-6cells
NiMH/NiCd: 1-15cells Pb: 2-20V DJI :3cells(LiHV)
Battery Capacity Range: NiMH/NiCd: 100-50000mAh
LiPo/Lilon/LiFe/UHV: 100-50000mAh Pb: 100-50000mAh
Charge Current: 0.1A-8.0A
Safety Timer: 1-120minutes off
Charge Wattage: 80W
Discharge Current: 0.1A-2.0A
Discharge Cut-off Voltage: NiMH/NiCd: 0.1-1.1 V/cell
LiPo: 3.0-3.3V/cell Lilon: 2.9-3.2V/cell
LiFe: 2.6-2.9V/cell LiHV: 3.1-3.4V/cell
Pb: 1.8V-2.0V/cell
Discharge Wattage: 8W
Balance Cells: 2-6 cells
Packaging Included:
1X SKYRC e680 Nano Duo Charger
