SZ-Speed 2207CS 2207 2600KV 3-4S Brushless Motor CW / CCW for RC Drone FPV Racing - 10.00 €


SZ-Speed 2207CS 2207 2600KV 3-4S Brushless Motor CW / CCW for RC Drone FPV Racing
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

SZ-Speed 2207CS 2207 2600KV 3-4S Brushless Motor CW / CCW for RC Drone FPV Racing

Specification:
Brand Name: SZ-Speed
Model: 2207CS
Item Name: 2207 2600KV 3-4S Brushless Motor
Version: CW Screw Thread / CCW Screw Thread ( Optional)
Configuration: 12N14P
Input Voltage: 3-4S Lipo
KV: 2600KV
Motor Width: 27.2mm
Motor Height: 32.8mm
Shaft Diameter: M5
Propelelr Adapter Shaft Thrad: M3
Weight: 31g
Recommend Propeller: 5 Inch Prop
Max. Thrust: 850g

Testing Table:

Propeller Voltage (V) Current (A) Thrust (g) RPM Power (W) Efficiency (g/W)
5045 2-blade 12 1.1 65 6343 13.2 4.92
5045 2-blade 12 2 115 8370 26.4 4.36
5045 2-blade 12 3 150 9557 36 4.17
5045 2-blade 12 3.9 185 10629 46.8 3.95
5045 2-blade 12 4.9 215 11571 58.8 3.66
5045 2-blade 12 5.9 250 12429 70.8 3.53
5045 2-blade 12 7 280 13517 84 3.33
5045 2-blade 12 7.9 310 13800 94.8 3.27
5045 2-blade 12 8.9 340 14143 106.8 3.18
5045 2-blade 12 10 370 15000 120 3.08
5045 2-blade 12 12.2 430 16286 146.4 2.94
5045 2-blade 12 14.1 475 17126 169.20 2.81
5045 2-blade 12 16.3 540 18244 195.6 2.76
5045 2-blade 12 18.5 585 19016 222 2.64
5045 2-blade 12 21 640 19684 252 2.54
5045 2-blade 12 23.6 690 20546 283.2 2.44
5045 2-blade 12 29 790 22204 348 2.27

Package Included:
1x 2207 2600KV Motor
