Upgrade SZ-Speed 1104C1 1104 6800KV 2-3S Brushless Motor for RC Drone FPV Racing - 10.00 €


Upgrade SZ-Speed 1104C1 1104 6800KV 2-3S Brushless Motor for RC Drone FPV Racing
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Upgrade SZ-Speed 1104C1 1104 6800KV 2-3S Brushless Motor for RC Drone FPV Racing

Specification:
Brand Name: SZ-Speed
Model: 1104C1
Item Name: 1104 6800KV 2-3S Brushless Motor
Configuration: 9N12P
Input Voltage: 2-3S Lipo
KV: 6800KV
Motor Width: 14mm
Motor Height: 13.9mm
Propelelr Adapter Shaft Thrad: M2
Weight: 5g
Recommend Propeller: 1.5-2.5 Inch Prop
Max. Thrust: 135g

Testing Table:
Propeller Voltage (V) Current (A) Thrust (g) Power (W) Efficiency (g/W)
3020 2-Blade 7.4 1.7 50 12.58 4
4.5 100 33.3 3
8.5 160 62.9 2.5
3020 3-Blade 11.1V 2.3 70 25.53 2.7
5.4 140 59.94 2.3
11.8 220 130.98 1.7

Package Included:
1x SZ-Spped 1104C1 6800KV Motor
