Way-Tec Stick 200 200mm Wheelbase 5mm Arm Carbon Fiber FPV Racing Frame Kit for RC Drone - 32.00 €


Way-Tec Stick 200 200mm Wheelbase 5mm Arm Carbon Fiber FPV Racing Frame Kit for RC Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Way-Tec Stick 200 200mm Wheelbase 5mm Arm Carbon Fiber FPV Racing Frame Kit for RC Drone

Specification:
Brand Name: Way-Tec
Model:Stick 200
Item Name: 200mm FPV Racing Frame Kit
Material: 3K Carbon Fiber
Wheelbase: 200mm
Arm Thickness: 5mm
The Width of Arm Plate: 8mm
Other Plate Thickness:2mm
Bottom Plate Thickness:3mm
The Height of Inner Space: 23mm
Camera Mounting Hole: 19mm width camera
Size: 171x171x37mm
Weight: 64.9g
Recommend Propeller: 4 Inch ( Max. 5.1 Inch )

Recommend Parts: ( Not Included )
Flight Controller: F3 / F4 FC ( 20x20mm Mounting Hole )
Brushless ESC: 20-30A ESC ( 4 In 1 Or Simple )
Brushless Motor: 22XX Series Motor
Lipo Battery: 3S
Camera: Camera with 19mm moutning width

The Following Parts are Suitable:
FC&ESC&VTX Flytower: 20x20mm Kingkong Omnibus F4 & 20A BL_S & 48CH VTX
HGLRC XJB F428 F4 FC & 28A BL_S 4 In 1 ESC

Brushless Motor: Racerstar BR2204 2300KV 3S Brushless Motor

Propeller: Gemfan Flash 4052 4.0x5.2 PC 3-blade Propeller 5mm Mounting Hole

Camera: RunCam Micro Swift 2 600TVL 2.1/2.3mm 1/3 OSD CCD FPV Camera

Lipo Battery: ZOP Power 11.1V 1500mAh 40C 3S Lipo Battery XT60 Plug

Package Included:
1x Stick 200 Frame Kit
